Zyyini 1161A Bluetooth4.1 Audio Receiver Board, 90dB Bluetooth4.1 MP3 Support WAV/APE/FLAC/MP3 Lossless Decoder Board Wireless 3.5mm Stereo Music Module Micro USB 5V for Smartphone

Price: $6.31
(as of Nov 14, 2022 21:29:12 UTC – Details)

Specification:
Item Type: Bluetooth Audio Receiver Board
Material: ABS+for PCB
Color: As Picture Shown
Weight: Approx. 39.0g/1.4oz
Power: 3.7-5V
Signal to Noise Ratio: 90dB
Crosstalk: -86dB
Support: A2DP / AVCTP / AVDTP / AVRCP / HFP
LOS> 15m
USB Power Supply: Universal Micro USB 5V Power Supply
3.7-5V Power Supply: External 3.7-5V Lithium Battery Power Conversion
LED Indicator: Blue Light in Bluetooth Mode
3.5mm Stereo Audio Interface: Output stereo sound source, insert headphones, connect amplifiers and other equipment

Instructions:
After turning on the power, the blue indicator light is on and enters the Bluetooth mode; the English “Bluetooth device is for pairing” is displayed on the screen, indicating that it has entered the Bluetooth mode and is waiting for pairing; the for “XY_BT” searched by the mobile phone’s Bluetooth is the decoder board The name of the device. , Click connect, the decoder board prompts “Bluetooth device connection is successful”, indicating that the decoder board is successfully connected to the mobile phone and can play music.

Package List:
1 x Bluetooth Audio Receiver Board1 x USB Power Cable
1 x 3.5mm Cable

Used for devices that do not accompany with Bluetooth function, using Bluetooth 4.1 technology.
Support automatic connection function, support for WAV/APE/FLAC/MP3 lossless decoding, stereo output.
3.5mm stereo audio interface, output stereo sound source, insert headphones, connect amplifier and other equipment.
Made of high quality materials, which can effectively wear, extend the service life.
Precise incisions and interfaces insure perfect suitability for mounting locations and ease of installation.
