8 Channel Bluetooth Live Studio Audio Mixer Mixing Console USB Professional, Professional Audio Mixer Soundboard Console Desktop, Connect Wired/Wireless/Condenser Microphone

Price: $100.00
(as of Nov 15, 2022 14:02:00 UTC – Details)

Specifications:
Name: Mixing Console
Input: AC 110V 50Hz 18W
Output: AC 18V X 2 350mA
Material: ABS
Color: Black&Red
Size: 400 x 340 x 37 mm

Functions:
※LR main mix
※2 Aux sends
※Recording
※2-Track monitoring and re play to LR
※Headphones and local monitor outputs
※Dedicated stereo, peak-retaining monitor meters
※Digital effect processor
※Metal jacks, gold-plated XLRs, sealed pots and switches
※External power adapter power supply

Technical Parameters:
※Max Input Level: +24dBu(MIC/Line); +20dbu(other line)
※Max Output Level: +26dBu(XLR); +20dBu(TRS)
※Master Meters: 10 segment -24dB to CLIP
※Channel Meters: 1 LED signal indication
※Frequency Response: 20Hz to 30KHz 0.5dB
※CMRR (MIC 1kHz): ＞75dB
※THD+N: ＜0.01%(Channel to mix out)
※Crosstalk at 1kHz: ＞85dB(Fader/Mute shutoff); ＞82dB(inter channel)
※Noise, rms 22Hz to 22KHz:
√EIN -122dBu
√Residual output noise ＜-90dBu
√L/R main mix noise＜-82dBu
√Aux mix noise ＜-82dBu
※Mono EQ:
√LF, shelving,+/-15dB, 12KHz
√HM, peak/dip,+/-15dB, 2.5KHz
√LF, shelving,+/-15dB, 80Hz
※Mono channel:
√XLR balanced, pin 2 hot, 2K ohm, Sensitivity -40 to +14dBu
√TRS balanced, tip hot, 10K ohm, Sensitivity -20 to +14dBu
√XLR, phantom +48V
※2-track return: RCA, unbalanced, 4K ohm, -2dBu
※2-track send: RCA, unbalanced, ＜75 ohm, -2dBu
※L/R output: XLR unbalanced, pin 2 hot, ＜75 ohm, +4dBu, Max.+22dBu
※FX/AUX output: TRS unbalanced, tip hot, ＜75 ohm, -2dBu, Max.+18dBu
※Headphones: TRS, tip L, ring R, 30 to 600 ohm headphones recommended
Size:40*34*3.7cm
Weight:4kg

Package Included:
1 x Mixing Console
1 x Charger (US Plug)
1 x User Manual
Please note: the mixing console itself will have bottom noise, noise close to 60BD
Responsive 3-band EQ
Electronically balanced XLR outputs with +26dBu drive capability
Bluetooth and MP3 player/recorder with simple HMI
Metal Jacks, Gold Plated XLRs, Sealed Pots and Switches
